Technical Specifications
Printing Technology
Fused Filament Fabrication (FFF)
Model
SPARKX i7
Build Volume
26 x 26 x 25.5 cm
Printing Speed
≤500 mm/s
Acceleration
≤10000 mm/s²
Printing Accuracy
100±0.1 mm
Layer Height
0.05 - 0.3 mm
Filament Diameter
1.75 mm
Nozzle Diameter
0.4 mm (compatible with 0.2 / 0.6 / 0.8 mm nozzles)
Maximum Nozzle Temperature
≤300°C
Maximum Heatbed Temperature
≤100°C
Build Plate
Dual-sided golden textured PEI
Extruder
Direct Drive Extrusion
Quick-Swap Hotend
Yes, tool-free
Leveling Mode
Full-auto leveling
Input Shaping
Supported
Pressure Advance
Supported
Display
2.85-inch Color Touchscreen
Connection Port
RS 485 (6-pin)
File Transfer
USB Drive / Wi-Fi
Wi-Fi
2.4 GHz
File Storage
8 GB eMMC
Firmware
Creality OS
Printable File Formats
G-code, 3MF
Slicing Software
Creality Print 6.3 or newer
Input Power
100–240V AC, 50/60Hz
Rated Power
700Watts (220V) / 400Watts (110V)
General Specifications
Compatible Filaments
PLA, PETG, PLA-CF, TPU (Shore 64D or harder)
CFS Lite Support
Yes
CFS Mini Support
Yes
AI Camera
720p with lighting
Spaghetti Detection
Yes, via AI camera
Build Plate Detection
Yes
Air Printing Detection
Yes
Power Loss Recovery
Yes
Filament Run-Out Resume
Yes
Filament Run-Out Detection
Yes
Filament Tangle Detection
Yes
Cutter Wear Monitoring
Yes
Print Status Light
Full-color RGB
UI Languages
English, German, Spanish, French, Italian, Portuguese, Russian, Turkish, Japanese, Korean, Arabic, Chinese
CFS Lite Multi-Colour System Specifications
Product
CFS Lite
Compatible Model
SPARKX i7
Number of Filament Slots
4
Multi-Colour Printing
Supported
Compatible Filaments
PLA, PETG, PLA-CF, TPU (Shore 64D or harder)
Filament Diameter
1.75 ±0.05 mm
Auto Filament Identification
Yes, via Creality RFID Filaments
Auto Filament Refill
Yes
Pre-Load Filament
Yes
Filament Run-Out Detection
Yes
Air Printing / Filament Tangle Detection
Yes
Drying Method
Desiccant
Power Supply
24V DC via RS 485 cable
Connection Port
RS 485 (6-pin)
Communication Protocol
RS 485, CAN 2.0
Filament Feeding Motors
4 (one per filament slot)
Status Indicators
4 white/red LED indicators
Compatible Spool Size
1 kg spool (195–202 mm diameter, 42–68 mm width)
Multiple CFS Lite Units
Not Supported
Dimensions & Weight
Build Volume
26 x 26 x 25.5 cm
Printer Dimensions
47 x 42.3 x 45.6 cm
Printer Net Weight
9.12 kg
CFS Lite Dimensions
36.2 x 22.7 x 36.4 cm
CFS Lite Net Weight
3.42 kg
Colour Combo Package Dimensions
55.7 x 50.5 x 52.9 cm
Colour Combo Gross Weight
18.5 kg
