Technical Specifications
Type
Mesh Wi-Fi 6 system for home coverage
Standards and Protocols
Wi-Fi 6, IEEE 802.11ax/ac/n/a (5 GHz), IEEE 802.11n/b/g (2.4 GHz)
Wi-Fi Speeds
AX1500
5 GHz
up to 1201 Mbps (802.11ax)
2.4 GHz
up to 300 Mbps (802.11n)
Operating Frequencies
2.4 GHz, 5 GHz
Wi-Fi Capacity
High
Data Streams
4
Protocols
IPv4, IPv6
WAN Types
Dynamic IP, Static IP, PPPoE, PPTP, L2TP
NAT Services
Port Forwarding, UPnP
IPTV
IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
Suitable for
2-4 bedroom houses
Antennas
2 internal – forming a signal-boosting array for wider coverage
General Specifications
Faster Connections
Wi-Fi 6 offers speeds up to 1,500 Mbps—1,201 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
Connect More Devices
OFDMA and MU-MIMO technology quadruples capacity for simultaneous transmission to more devices
Enhanced Seamless Coverage
Achieve uninterrupted whole-home coverage with a clearer and stronger Wi-Fi signal provided by Wi-Fi 6
Ultra-Low Latency
Greater reduction in latency enables more responsive gaming and video chatting
One Unified Network
Multiple units form a whole-home network that automatically selects the best connection as you move around your home
Robust Parental Controls
Limit your online time and block inappropriate websites according to a unique profile you create for each family member
Easy Setup
The Deco app guides you step-by-step through the setup
Dual-Band
Distributes devices across bands for optimal performance
Transmission Technologies
OFDMA – simultaneous communication with multiple Wi-Fi 6 clients
MU-MIMO 2x2 – simultaneous communication with multiple devices
Beamforming – strengthens the signal toward connected devices
TP-Link Mesh – unified coverage via Ethernet or wireless connection between Deco units
Operating Modes
Router Mode, Access Point Mode
Network Security
SPI Firewall, Access Control
Wi-Fi Encryption
WPA-Personal, WPA2-Personal, WPA3-Personal
Parental Controls
User profile creation, Professional content filter, Family Time, Bedtime, Off Time, Time Rewards, Online time ranking, Internet pause per device, Weekly and monthly reports
Management
Deco App (iOS / Android)
Ethernet Ports
2× Gigabit ports per Deco unit
System Requirements
Android 5.0 or later, iOS 9.0 or later
Certifications
CE, FCC, RoHS, JPA, JRF, VCCI, NCC, BSMI
Operating Temperature
0℃~40℃
Storage Temperature
-40℃~60℃
Operating Humidity
10%~90% non-condensing
Storage Humidity
5%~90% non-condensing
