Technical Specifications
Type
Mesh Wi-Fi 7 system for whole-home coverage
Standards and Protocols
Wi-Fi 7 (IEEE 802.11be), IEEE 802.11be/ax/ac/n/a (5 GHz), IEEE 802.11be/ax/n/b/g (2.4 GHz)
Wi-Fi Speeds
BE3600
Wi-Fi (2.4 GHz)
688 Mbps
Wi-Fi (5 GHz)
2880 Mbps
Operating Frequencies
2.4 GHz, 5 GHz
Wi-Fi Capacity
Very high (supports over 150 devices simultaneously)
Spatial Streams
4 streams (2x2 per band)
Wi-Fi Technologies
Multi-Link Operation (MLO), 4K-QAM, Beamforming, Multi-RUs
Maximum Channel Width
160 MHz
Security
WPA-PSK, WPA2-PSK, WPA3-SAE
Protocols
IPv4, IPv6
WAN Types
Dynamic IP, Static IP, PPPoE, PPTP, L2TP
NAT Services
Port Forwarding, UPnP
IPTV
IGMP Proxy, IGMP Snooping, Bridge, VLAN Tagging
Operating Modes
Router Mode, Access Point Mode
Coverage
Up to 460 m² (2-pack, suitable for 2-4 rooms)
General Features
Wider Wi-Fi Coverage
MERCUSYS Mesh technology provides seamless whole-home coverage with seamless roaming and optional Ethernet backhaul
Dual-Band
Distributes devices across 2.4 GHz and 5 GHz for optimal performance
Transmission Technologies
OFDMA – simultaneous communication with multiple devices
Multi-Link Operation (MLO)
Combines connections for higher speed and stability
160 MHz Channel
Increased bandwidth for higher speeds
4K-QAM
Higher data density
MU-MIMO
Simultaneous communication with multiple devices
Beamforming
Focused signal toward connected devices
Operating Modes
Router Mode, Access Point Mode
Network Protection
Basic firewall, access control
Network Security
Protection for connected devices and basic threat isolation (no advanced suite like HomeShield)
Wi-Fi Encryption
WPA-Personal, WPA2-Personal, WPA3-SAE
Guest Network
1x 5 GHz and 1x 2.4 GHz guest network
Parental Controls
Basic access control and device management
Operating Temperature
0°C to 40°C
Storage Temperature
-40°C to 60°C
Operating Humidity
10% - 90% non-condensing
Storage Humidity
5% - 90% non-condensing
Antennas
Internal high-performance antennas with Beamforming
Mesh Features
Seamless roaming, unified Wi-Fi network, automatic best node selection, support for 802.11k/v/r
Management
Via MERCUSYS app (mobile), local and remote management
Suitable For
Large homes, multiple rooms/floors, many connected devices
