Technical Specifications
Type
Wi-Fi 7 router
Standards and Protocols
Wi-Fi 7 (IEEE 802.11be), IEEE 802.11be/ax/ac/n/a (5 GHz), IEEE 802.11be/ax/n/b/g (2.4 GHz)
Wi-Fi Speeds
BE3600
Wi-Fi (2.4 GHz)
688 Mbps
Wi-Fi (5 GHz)
2880 Mbps
Operating Frequencies
2.4 GHz, 5 GHz
Wi-Fi Capacity
Very high
Wi-Fi Technologies
Multi-Link Operation (MLO), 4K-QAM, OFDMA, MU-MIMO, Beamforming
Maximum Channel Width
160 MHz
Security
WPA-PSK, WPA2-PSK, WPA3-SAE
Protocols
IPv4, IPv6
WAN Types
Dynamic IP, Static IP, PPPoE, PPTP, L2TP
NAT Services
Port Forwarding, UPnP
IPTV
IGMP Proxy, IGMP Snooping, Bridge, VLAN Tagging
Operating Modes
Router Mode, Access Point Mode
General Features
Wider Wi-Fi Coverage
High-performance coverage with 4x external antennas and Beamforming
Dual-Band
Distributes devices across 2.4 GHz and 5 GHz for optimal performance
Transmission Technologies
OFDMA – simultaneous communication with multiple devices
Multi-Link Operation (MLO)
Combines connections for higher speed and stability
160 MHz Channel
Increased bandwidth for high speeds
4K-QAM
Higher data density
MU-MIMO
Simultaneous communication with multiple devices
Beamforming
Focused signal toward connected devices
Operating Modes
Router Mode, Access Point Mode
Mesh Compatibility
EasyMesh support
Network Protection
SPI firewall, access control, IP & MAC binding
Wi-Fi Encryption
WPA-Personal, WPA2-Personal, WPA3-SAE
Guest Network
2.4 GHz and 5 GHz guest networks
VPN Client
OpenVPN, PPTP, L2TP/IPSec
QoS
Traffic prioritization and bandwidth management
Parental Controls
Supported
Antennas
4x external high-performance antennas
Management
Via MERCUSYS app (mobile), local and remote management
Suitable For
High-speed internet, gaming, streaming, smart homes
